JODHPURI BIG BOTTOM W/O LEG BURNER

JODHPURI BIG BOTTOM W/O LEG BURNER

Categories Bottom Leg Burner Jodhpuri, LPG Burners, LPG Burners & Components

Additional information

These burners are recommended to be used at a pressure of 0.3 kg/cm² (4.5 PSIG), however, this may be varied by ± 25% the heat output being varied accordingly.

Additional information

Model Number	JODHPURI BIG
Product Type	Number 2
Material	CAST IRON
Head Diameter	160	MM	6.300	INCH
Total Length	450	MM	17.800	INCH
Optimum Working Pressure	0.3	KG/CM3	4.5	PSIG
Consumption Per Hour	1.25	KGS	2.5	LBS
Rated Heat Output	14,500	KCAL/HR	57,500	BTU/HR
Gas	LPG / NATURAL GAS
